PLD1600 mixing station batching machine production and sales, can be customized according to the different needs of customers for their own working environment PLD1600 batching machine concrete mix ratio is high, can be equipped with more than three kinds of materials, with various types o
PLD1600 mixing station batching machine production and sales, can be customized according to the different needs of customers for their own working environment PLD1600 batching machine concrete mix ratio is high, can be equipped with more than three kinds of materials, with various types of concrete mixers and other metering devices supporting the use, Can be combined into automatic and semi-automatic mixing station.
PLD1600 concrete batching machine is a kind of front desk automatic batching machine which can be used with mixer. Divided into one-way and two-way, it looks at the concrete ratio designed by the user to automatically complete the sand, stone, cement and other two to four materials (secondary concrete) dosing procedures. PLD1600 concrete batching machine is divided into 2 bin batching machine and 3 bin batching machine two kinds of products using electronic weighing, microcomputer control, digital display, wired remote control operation, with accurate weighing, high batching precision, fast speed, strong control function, easy operation and other advantages.
model | Weighing hopper capacity | Storage hopper capacity | productivity | Batching accuracy | Weighing value | Number of ingredients | Feeding height | Feeding belt speed | power | Total capacity | Overall dimension |
PLD800 | 800L | 2×1.5m³ | 48m³/h | ±2% | 2000 | 2-3species | 2400 | 3 | 3×3 | 2450 | 6000×2000 |
PLD1200 | 1200L | 4×2.5m³ | 56m³/h | ±2% | 3000 | 2-4species | 3000 | 1 | 5×3 | 4500 | 9500×2200× |
PLD1600 | 1600L | 4×5m³ | 75m³/h | ±2% | 3000 | 2-5species | 2900 | 1 | 5×3 | 5600 | 12000×2200× |
PLD2400 | 2400L | 4×10m³ | 120m³/h | ±2% | 4000 | 2-5species | 2900 | 1.6 | 11 | 85000 | 10000×3000× |
PLD3200 | 3200L | 4×18m³ | 160m³/h | ±2% | 5000 | 2-5species | 2300 | 1.6 | 11 | 10500 | 14500×3000× |
PLD4800 | 4800L | 4×25m³ | 160m³/h | ±2% | 8000 | 2-5species | 2300 | 1.25 | 11 | 14000 | 15520×3900× |
1. Quality assurance sufficient supply, large production scale, products are guaranteed.
2. Convenient and practical products are guaranteed from the details, easy to operate, high quality to provide excellent experience.
3. Excellent service to provide excellent service, after-sales protection.
4. Mature technology Mature technology, standardized business operation, to bring good experience to customers.
5. Green environmental protection Energy saving, green environmental protection.
